Product description
The Roger GNSS-RAS-8 is an active 1-to-8 splitter that distributes the signal of one GNSS antenna to eight receivers. It is designed for GNSS time synchronization and signal distribution in server halls, laboratories and other facilities where reliable GNSS reception is required.
The splitter covers all GNSS constellations and the Iridium band within 1.15–1.63 GHz. The redundant power input keeps the signal on even if one power supply fails; the unit also works with a single power supply. The outputs are loaded with 200-ohm resistors, so the receivers do not raise false antenna alarms.
Features
- 8 outputs, 10 dB gain
- Redundant 12 VDC power input
- Status LEDs for antenna current and both power supplies
- +5 VDC antenna feed from the RF input
- Installation in a 19-inch rack or on a desk
Technical specifications
- Frequency range: 1.15–1.627 GHz (GPS, GLONASS, Galileo, BeiDou, Iridium)
- Gain: 10 dB (7.5–12.5 dB)
- Output port isolation: over 21 dB, amplitude balance 0.5 dB, phase balance under 5°
- Connectors: RF input 1 × SMA female, RF outputs 8 × SMA female
- Maximum input power: −20 dBm
- Antenna feed: 5 VDC, max. 100 mA
- Power input: 2 × M8 4-pin male, 10.8–13.2 VDC, power consumption 3 W
- Operating temperature: −25…+55 °C
- Dimensions and weight: 483 × 212 × 44 mm (19-inch, 1U), 1.7 kg
- Package contents: splitter, rack brackets, rubber feet and user manual in English
The power supplies are ordered separately, for example the Roger GNSS-PS-AC, GNSS-PSU1-IP67 or GPSR-PS-DC-12/24. Unused outputs are terminated with 50-ohm SMA terminators.
